LionRock IP20 Energy Cabinet With CAN Communication Natural Heat Radiation Cooling

Basic Information
Place of Origin: Dongguan China
Brand Name: LionRock
Model Number: EC1010V
Minimum Order Quantity: negotiate
Price: negotiate
Packaging Details: export packing
Delivery Time: negotiate
Payment Terms: TT
Detail Information
Color: Black Dimension (W X D X H): 600 Mm X 600 Mm X 2000 Mm
Weight: 56 Kg Inner Rack & Space: 34 U, 19-inch Rack
Protection Level: IP20 (EN 60529) Cooling Mode: Natural Heat Radiation
High Light:

IP20 Energy Cabinet


Energy Cabinet LionRock

Product Description

Wide DC Input Range Telecom Power Cabinet



The EC1000 series telecom power indoor cabinet is new platform generation designed to fit customer needs, configuration flexibility and
supports variety of applications. The equipment cabin reserves 19-inch rack space for other equipments. The cabinet is well suited for power,
batteries and telecom equipment.



- Small size, easy deployment
- Compact design for installation of equipment
- Intelligent battery management function helps to prolong battery lifespan
- Easy installation & maintenance by front door design
- Wide operating DC input range
- Full galvanic isolation
- Advanced max power point tracking routines
- Support CAN communication
- Open protocol of maintenance interface
- Anti-theft design



- Indoor
- Solar / diesel / grid hybrid system


General Specification

System Dimension (W x D x H) 600 mm x 600 mm x 2000 mm
Weight 56 kg (without rectifier modules and battery)
Installation Mode Indoor cement floor installation
Cabling Mode From the top
Maintenance Mode From the front
Cabinet Material Hull, inside frame, & base: steel
Cabinet Color Black: RAL 9004
Cable Entry Detail Cable entry from top of cabinet
Equipment Cabin Inner Rack & Space 34 U, 19-inch rack
Protection Level IP20 (EN 60529)
Cooling Mode Natural heat radiation
Environment Operating Temperature -10 ºC to +45 ºC
Storage Temperature -40 ºC to +70 ºC
Operating Relative Humidity 5% to 95% (no condensation)
Altitude 0 to 4000 m (1 ºC per 200 m temperature derating from 2000 to
4000 m)

Remark: MPPT: Maximum Power Point Tracking; HFSM: High Frequency Switch Module
