| Place of Origin: | Dongguan China |
|---|---|
| Brand Name: | OwlEye |
| Minimum Order Quantity: | negotiate |
| Price: | negotiate |
| Packaging Details: | export packing |
| Delivery Time: | negotiate |
| Payment Terms: | TT |
| Deployment Solution: | Support Both 'On CloudSolution' (Amazon) And 'On Premises Solution' | Networking: | 4G, Ethernet |
|---|---|---|---|
| Energy Management: | Equipment Energy Acquisition And Analysis For Today, Past 7 Days, Past 30 Days | Sites Management: | Multiple Sites Management With Flexible User Defined Parameters Setting |
| Assets Create And Management: | Create And Manage Multiple Assets | Site Configuration: | Site Configuration Information Batch Copy |
| High Light: | ODM IOT Remote Monitoring System,OEM IOT Remote Monitoring System,Ethernet Project Configuration Management |
||
Project Configuration Management IOT Remote Monitoring System
Remote Monitoring System Functions and Features - Project Configuration Management
Device Management
|
Objective Verify Device Management |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.Project Configuration > Device Management in the Administration Console | The Device Management page shows up. |
| 2.Click the Add button on the right to add FSU. |
Get a FSU group. |
| 3.Select the first-level group and click the "Add" button on the right to add the second-level group. | Get a FSU. |
| Remarks | |
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
|
Objective Verify Device Management |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
|
Procedure |
Expected Result |
| 1.Search Rectifier in the "Asset Type" on the right hand side in Site List > click the asset name to access Rectifier Detailed Block | Rectifier Detailed Block shows up |
| 2.Click and Switch to another site | Users are able to see Rectifiers of another site |
| 3.Click and Switch to another Rectifier in the same site | Users are able to see parameters of another rectifier in the same site. |
| 4.Performance Metrics | User can see readings of the selected parameters |
| Remarks | |
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
Group & Asset Management
|
Objective Verify that the interaction between the User panel and the Master panel is normal. |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1. Project Configuration > Group & Asset Management in the Administration Console | The Group & Asset Management page shows up. |
| 2. Click the Add button on the right to add a first-level group. | Get a first-level group. |
| 3. Select the first-level group and click the "Add" button on the right to add the second-level group. | Get a second group. |
| 4. Select the secondary group, click the "Add" button on the right to site. | Get a site. |
| 5. Select the site and click the "Add" button on the right to add assets. | Select the desired asset model to create an asset. |
|
6. Click "Display Configuration" on the right side of the asset. |
One can choose the data items to be displayed and where to display. |
|
7. Click the site under second group and find Quickly Create Sites, enter the number of sites |
Specific number of sites are quickly created based on the site configuration |
|
Remarks |
|
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
