Detailed Blocks Management IOT Remote Monitoring System
Remote Monitoring System Functions and Features - Detailed Blocks Management
AC Generator Detailed Block
|
Objective Verify AC Generator Detailed Block |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.Login OwlEye Server > Select target site on the tree in the Site List > search target type in the "Asset Type" on the right hand side > click the asset name to access AC Generator Detailed Block. | AC Generator Detailed Block shows up |
| 2.Click and Switch to another site |
Users are able to see AC Generator Detailed Block of another site |
| 3.Switch the mode from Auto to Manual | Generator controller under Manual mode |
| 4.Click the remote start button under Manual mode | Generator remotely starts |
| 5.Click the remote stop button under Manual mode | Generator remotely stops |
| 6.Performance Metrics | User can see readings of the selected parameters |
|
Remarks: Remote control function like remote start/stop, remote mode switch requires to enter password |
|
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
Temperature & Humidity Sensor Detailed Block
|
Objective Verify Temperature & Humidity Sensor Detailed Block |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.Search Temperature and Humidity in the "Asset Type" on the right hand side in Site List > click the asset name to access Temperature & Humidity Sensor Detailed Block. | Temperature & Humidity Detailed Block shows up |
| 2.Click and Switch to another site | Users are able to see temperature and humidity values of another site |
| 3.Page goes down | Users can see both values and line charts |
| 4.Put the mouse in the line charts and scroll up | The line charts expand and there are readings showing up when putting the mouse on the line. |
|
Remarks |
|
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
Heat Exchanger Detailed Block
|
Objective Verify Heat Exchanger Detailed Block |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.search Heat Exchanger in the "Asset Type" on the right hand side in the Site List > click the asset name to access Heat Exchanger Detailed Block. | Heat Exchanger Detailed Block shows up |
| 2.Click and Switch to another site | Users are able to see Heat Exchanger Detailed Block of another site |
| 3.Performance Metrics | User can see readings of the selected parameters |
| Remarks | |
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
HR Cabinet Type Air Conditioner
|
Objective Verify HR Cabinet Type Air Conditioner Detailed Block |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.Search HR Cabinet type air conditioner in the "Asset Type" on the right hand side in the Site List > click the asset name to access HR Cabinet Type Air Conditioner Detailed Block. | HR Cabinet Type Air Conditioner Detailed Block shows up |
| 2.Click and Switch to another site | Users are able to see HR Cabinet Type Air Conditioner of another site |
| 3.Performance Metrics | User can see readings of the selected parameters |
| Remarks | |
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
Three Phase AC Meter Detailed Block
|
Objective Verify Three Phase AC Meter Detailed Block |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.Search Three phase AC Meter detailed block in the "Asset Type" on the right hand side in Site List > click the asset name to access Three Phase AC Meter Detailed Block. | Three Phase AC Meter Detailed Block shows up. |
| 2.Click and Switch to another site | Users are able to see Three Phase AC Meter of another site. |
| 3.Performance Metrics | User can see readings of the selected parameters. |
| Remarks | |
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
Rectifier Detailed Block
|
Objective Verify Rectifier Detailed Block |
|
|
Prerequisites - The OwlEye Server is running properly. |
|
| Procedure | Expected Result |
| 1.Search Rectifier in the "Asset Type" on the right hand side in Site List > click the asset name to access Rectifier Detailed Block | Rectifier Detailed Block shows up. |
| 2.Click and Switch to another site | Users are able to see Rectifiers of another site. |
| 3.Click and Switch to another Rectifier in the same site | Users are able to see parameters of another rectifier in the same site. |
| 4.Performance Metrics | User can see readings of the selected parameters. |
| Remarks | |
| Test Result | |
|
Test Conclusion □ Passed □ Failed □ Exempted |
|
